What is the role of the subwoofer of the speaker?

2022-05-24 15:57:02

In many cases of home theater system construction, the selection and adjustment of subwoofer caixas de som are the most easily overlooked.

Many users don't even understand why a home theater system must have a subwoofer caixas de som? Can't the main speaker replace the subwoofer palestrante? Or is there no clue when choosing a product. Is the larger the subwoofer palestrante size, the better the effect? How to adjust the phase of the subwoofer palestrante? For practical purposes, interpret the doubts or problems encountered.

1. Subwoofer is essential

Whether it is the Dolby Digital, DTS built in early DVD, or the current sound encoding such as Dolby Atmos, Dolby HD, DTS True HD, etc., there are independent subwoofer palestrante channels.

That is to say, under the standard of these formal multi-channel sound effects encoding, one or more active subwoofer caixas de som must be matched to show the midrange, bass and even subwoofer palestrante that should be in the audio. faixa de frequência.

2. Don't judge the quality by the size of the subwoofer

The size of the subwoofer palestrante involves factors such as the driving power of the subwoofer palestrante itself, the type of the box, the efficiency and instantaneous performance of the single unit.

Although a large-sized subwoofer palestrante can push the air with a larger area, thereby producing a more component low frequency, but it has a much heavier cone weight than a small-sized subwoofer palestrante. If you want to push it out for a stronger low frequency, In the amplifier circuit part, it is necessary to have stronger output power first.

In addition, the instantaneous performance of large-sized subwoofer palestrante is often not as good as that of small-caliber subwoofer caixas de som, so the speed of low-frequency transmission is often not fast enough, and even the phenomenon of sound "smearing" occurs. Therefore, the use of large-sized subwoofer caixas de som mostly only provides larger low-frequency components, and it may not be as light and agile as small-sized subwoofer caixas de som in the sense of speed.

3. Main speakers instead of subwoofer caixas de som? Sound effects at a discount

The home theater system cannot determine whether the mid- and low-frequency range (especially the low-frequency part) of the entire combination is sufficient by the size of the speaker alone, because the normal multi-channel system will most likely cross the frequency band below 80Hz or 90Hz of the response frequency band. Take responsibility for the subwoofer palestrante. For users who do not consider buying a subwoofer palestrante, the main speaker can also be set to full frequency through settings.

But this setting is bound to cause a greater burden on the amplifier circuit of the main speaker and the cinema power amplifier itself. In addition, the subwoofer palestrante can independently adjust the volume, crossover point and phase, and can also adjust the placement according to the size of the space. Home theater systems with subwoofer caixas de som have more flexibility in overall debugging.

4. Subwoofers are phase-sensitive

Simply put, in the placement adjustment of the subwoofer palestrante, quando o subwoofer palestrante E os alto -falantes do canal esquerdo e direito soam na mesma direção, a fase de som dos dois deve estar próxima do mesmo ângulo de fase.

Se o subwoofer palestrante é colocado em uma posição "coberto" com o falante, o subwoofer palestrante formará um estado antifásico de 180 graus com os alto-falantes esquerdo e direito. Neste momento, se a fase do subwoofer palestrante O backplane não está definido em 180 graus (fase reversa), não apenas a baixa frequência do subwoofer será sempre emitida na parte traseira do campo sonoro, ou algumas bandas de frequência entre o subwoofer e o alto -falante serão emitidas. Faz com que a fase seja inconsistente e, mesmo devido à sobreposição ou cancelamento da fase, o aumento ou desaparecimento de algumas faixas de frequência de baixa frequência é formado.

Quando ajustamos a fase positiva e negativa do subwoofer palestrante, podemos seguir o volume de baixa frequência ouvido na posição de escuta. Ou seja, quando tocamos uma música com um senso completo de baixa frequência, você pode sentar na posição de escuta e depois mudar as fases positivas e negativas do subwoofer palestrante Por sua vez, desde que você possa sentir o forte efeito de baixa frequência na posição de escuta, a fase é a que faz você sentir as baixas frequências.

5. A baixa frequência é uma bagunça, como devemos depurar?

De um modo geral, subwoofer caixas de som Muitas vezes, fazem com que algumas faixas de frequência desapareçam, mas algumas bandas de frequência são excessivas por causa da faixa de frequência, cancelamento de fases ou aumento do espaço.

Primeiro de tudo, quando estamos ajustando o subwoofer palestrante, podemos começar a partir das quatro partes do posicionamento e ângulo do subwoofer, seleção de fases, volume e ponto de cruzamento como itens de ajuste. Durante a depuração inicial, podemos ajustar o volume primeiro e, finalmente, ajustar o volume apropriado. Depois que o problema da confusão de baixa frequência é aprimorado até certo ponto, use a música e os filmes com os quais você conhece como detecção de reprodução. Depois de ajustar as configurações várias vezes dessa maneira, o efeito do subwoofer palestrante será melhorado até certo ponto.
